Description
Cockpit
Stem Alloy Trail Stem, 35mm bar bore.
Saddle Bridge Comp, Hollow Cr-mo rails, 155/143mm.
Tape Specialized Trail Grips.
Handlebars Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width.
SeatPost X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4/S5: 175mm, S6: 190mm.
Frameset
Seat Binder Alloy, 38.6mm.
Frame Specialized M5 premium alloy, headset adjust, BB height adjust, S-Sizing, internal cable routing, 150mm travel, 148mm spacing.
Wheels & Tires
Rear Hub Alloy, sealed cartridge bearings, 148mmx12mm thru-axle, 28h.
Front Hub Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h.
Front Tire Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29×2.6″.
Spokes DT Swiss Industry.
Rear Tire Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5×2.6″.
Rims Specialized 29, hookless alloy, 30mm inner width, tubeless ready.
Inner Tubes Standard, Presta Valve.
E-Bike
Wiring Harness Custom Specialized wiring harness.
Charger Custom charger, 42V4A w/ Rosenberger plug, 100-240V.
Motor Specialized 2.2 Custom Rx Trail Tuned Motor.
Battery Specialized M3-700, Integrated battery, 700Wh.
UI/Remote Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, ANT+/Bluetooth®, w/Handlebar remote.
Suspension
Rear Shock FOX FLOAT X Performance, LSR, 2-position lever, 55x210mm.
Fork Fox Rhythm 36, S1: 150mm travel, S2-S6: 160mm travel.
Drivetrain
Crankset Praxis Forged/Custom Offset/ISIS Spindle Interface, 160mm.
Rear Derailleur SRAM GX Eagle, 12-speed.
Shift Levers SRAM GX, trigger, 12-speed.
Chain SRAM NX Eagle, 12-speed.
Chainrings SRAM X-Sync Eagle, 104 BCD, 34t, steel.
Cassette Sram XG-1275, 12-speed, 10-52t.
Brakes
Rear Brake SRAM Code R, 4-piston caliper, hydraulic disc, 200mm.
Front Brake SRAM Code R, 4-piston caliper, hydraulic disc, S1-S3: 200mm, S4-S6: 220mm.
Weight
Weight 23.92kg (52 lb, 11.8 oz).
Weight Size S4.
