Description
Technical Information :
| Fork |
FOX 38 Rhythm, Grip damper, 180mm travel, 37mm rake
|
| Seat Binder | Alloy, 38.6mm |
| Frame |
Specialized M5 Premium Aluminum, 27.5 Trail Geometry, integrated down tube battery, enclosed internal cable, Command Post routing, 148mm spacing, fully sealed cartridge bearings, 180mm of travel
|
| Rear Shock |
FOX DHX Performance Series coil. Springs: S2: 450lb, S3: 500lbs, S4: 550lbs, S5: 600lbs
|
| Chainrings | 32t Praxis, steel |
| Crankset | Praxis Forged Alloy, 160mm |
| Rear Derailleur | Shimano Deore XT LINKGLIDE, 11-speed |
| Chain | Shimano LINKGLIDE, 11-speed |
| Cassette | Shimano LINKGLIDE, 11-speed, 11-50t |
| Shift Levers | Shimano Deore XT, 11-speed |
| Stem | Alloy Trail Stem, 35mm bar bore |
| Saddle | Bridge Comp, Hollow Cr-mo rails, 155/143mm |
| Tape | Specialized Trail Grips |
| Handlebars |
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width
|
| SeatPost |
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SRL LE lever, 34.9mm, S: 125mm, M/L: 150mm, XL: 170mm
|
| Front Tire | Butcher Grid Gravity 2Bliss Ready T9, 27.5 x 2.6″ |
| Rear Tire | Butcher Grid Gravity 2Bliss Ready T9, 27.5 x 2.6″ |
| Spokes | DT Swiss Industry |
| Inner Tubes | Presta, 40mm valve |
| Rims |
Roval 27.5″ Alloy DH, 28mm internal width, 32h, tubeless ready
|
| Front Hub |
Shimano MT400-B, Centerlock, 15x110mm thru-axle, 32h
|
| Rear Hub |
Shimano MT400-B, Centerlock, 12×148 Boost, 32h
|
| Wiring Harness | Custom Specialized harness |
| Charger |
Custom charger, 42V4A w/ Rosenberger plug, 100-240V
|
| Motor | Specialized 2.2 Custom Rx Trail Tuned Motor |
| Battery |
Specialized M2-500, integrated battery w/rock guard, 500Wh
|
| UI/Remote |
Specialized TCU, 10-LED State of charge, 3-LED Ride Mode display, ANT+/Bluetooth®, w/Handlebar remote
|
| Front Brake |
Shimano SLX M7120, 4-piston caliper, hydraulic disc, 203mm rotor
|
| Rear Brake |
Shimano SLX M7120, 4-piston caliper, hydraulic disc, 203mm rotor
|
| SWAT |
Specialized Z-Cage, Swat CC Multi Tool in steerer tube without Chaintool
|
