E-Power X Vert Pro Team

Corratec

E-Power X Vert Pro Team

4,499.00

Clear
SKU: N/A Categories: , ,

Frame: Corratec E-Power X Vert Gent Components:Bosch PowerTube 750Wh

  • Wheel Split – Front 29 Inch Tire and Rear 650B+.
  • Trail hardtail with 120 mm travel and a flatter steering head angle.
  • Shadow Edge Tube 3.0 for an elegant integration of the 750Wh Bosch battery.

MAIN:

FRAME:
Corratec E-Power X Vert Gent
FORK:
Rockshox RS Recon 29″ +
BREAKES:
Shimano Disc Brake MT420 front +Shimano MT410 rear +
STEM:
ZZYZX SL Alloy
HANDLE BAR:
ZZYZX SL Alloy Handlebar +
SADDLE:
Selle Italia Model X
SEAT POST:
Kindshock 860i +

DRIVE:

CHAINWHEEL:
ZZYZX E-Power Crank +
CASSETTE:
Shimano DEORE SLX 12S +
REAR DERAILLEUR:
Shimano DEORE XT 12S
SHIFT LEVERS:
Shimano DEORE SLX

WHEELSET:

RIM:
ZZYZX Cross Attack 29 Boost front +ZZYZX Cross Attack 650B Boost rear +
TIRE:
Schwalbe Nobby Nic 29″ front +Schwalbe Nobby Nic 650B rear +

SPECIAL:

CHAINWHEEL RATIO:
1s; 34
CASSETTE RATIO:
12s; 10 12 14 16 18 21 24 28 33 39 45 51
FORK SUSPENSION
TRAVEL:
120 mm
SIZE BRAKE DISC
180 mm front
180 mm rear
ENGINE:
BOSCH Performance Line CX +
BATTERY:
BOSCH PowerTube 750Wh +

Shadow Edge Tube 3.0

New generation of the most stable and safest corratec E-bike frame

The bioinic structure of the battery cover provides superior grip when removing the battery. The lid, which is fully integrated into the frame, impresses with its flowing lines and ensures a clean look. The special designed ventilation slots provide the strong Bosch engine with sufficient fresh air and prevent it from overheating. This way the engine ensures maximum powert at any time. In order to increase the torsional rigidity of the down tube an additional bar has been integrated inside the frame. This feature ensures maximum control and safety, even on difficult trails. The locking mechanism, specially developed for the Shadow Edge Tube 3.0, reduces the cutout of the down tube thanks to its smart mounting and thus increases the torsional stiffness of the frame. The double safety locks the battery firmly in the slot and prevents it from rattling or loosening while riding.

Wheel Split

A corratec bike with Wheel Size Split performes a lot better in flowy trails which have a lot of turns. It is far easier to lay the bike over into the turns, there is more room to move around on the bike and the acceleration out of slow speed turns and situations is great. The smaller rear wheel is marginally more agile and precise on technical trails. On bigger jumps the 27.5 rear wheel gives a little more clearance and there is less risk of the mid air butt buzzing which is heavily unsettling. By the way a unique point of the wheel size split: The 27,5 bike also manuals a lot easier, picking the wheel up and holding it into a manual is easier than with a 29″ rear wheel.

Additional information

Size

44, 54

Brand

Corratec

Suspension Type

Hardtail
