Description
Technical specifications :
Frameset
Frame : FACT 11m carbon chassis and rear-end, asymmetrical design, 29 Trail Geometry, SWAT™ Door integration, flip chip Head Tube/Bottom Bracket adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm UDH compatible rear spacing, sealed cartridge bearing pivots, 130mm or travel
Seat Binder : Alloy, 38.6mm
Suspension
RearShock : FOX FLOAT DPS Factory, Rx Trail Tune, EVOL Air sleeve, Kashima Coat, 3-position adjustment w/ Open Mode Adjustment, 190x45mm
Fork : FOX FLOAT 34 Factory, GRIP2 damper, Kashima Coating, 15x110mm, 44mm offset, 140mm of travel
Cockpit
Saddle : Bridge, 155/143mm, Hollow Ti rails
SeatPost : RockShox Reverb AXS, 30.9, 1X remote, (S1: 100mm, S2: 125mm, S3: 150mm, S4-S6: 170mm)
Vote : Deity, 35.0mm
Handle bars : Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm, 35.0mm
Grips : Deity Grips
Brakes
Front brake : SRAM Code Ultimate Stealth, 4-piston caliper, hydraulic disc, 200mm HS2 Rotor
Rear Brake : SRAM Code Ultimate Stealth, 4-piston caliper, hydraulic disc, 180mm HS2 Rotor
Drivetrain
Shift Levers : SRAM AXS POD Ultimate Controller
Rear Derailleur : SRAM XX Eagle Transmission Derailleur
Cassette : SRAM XX SL Eagle Transmission Cassette, 12spd, 10-52t
Chain : SRAM XX SL Eagle Transmission Flattop Chain
Crankset : SRAM XX Eagle Crankset, Carbon, Integrated Guard, 55mm Chainline, S1: 165mm, S2-S5: 170mm, S6: 175mm
Chain rings : 32T
Bottom Bracket : SRAM DUB, BSA 73mm Wide, Threaded
Wheels & Tires
Rims : Roval Control 240, hookless carbon, 29mm inner width, hand-built, 2Bliss Ready
Front Hub : DT Swiss 240, sealed cartridge bearings, 15x110mm spacing, 28h
Rear Hub : DT Swiss 240, Ratchet EXP, 36t engagement, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
Spokes : DT Swiss Competition Race
Front Tire : Butcher, GRID casing, GRIPTON® T9 compound, 29×2.3″
Rear Tire : Purgatory, GRID casing, GRIPTON® T7 compound, 29×2.3″
Inner Tubes : Standard, Presta valve
Weight
Weight : 12.75kg (28 lb, 1.7 oz)
WeightSize : S4
